Cycloidal Drive - printable
cycloid
cycloidal
cycloidal drive
drive
fushigi
wankel
Downloads0
Likes0
Saves0
Comments0
PublishedFebruary 16, 2026
About
100:1 gearlook at http://www.youtube.com/watch?v=vvIyG6DhlZE for milled versionThe ball bearings are 623. The big ball bearings are 6201.The two inner wheels must be glued together.The excenter shaft has to be made of steel.
---
Imported from Thingiverse: https://www.thingiverse.com/thing:3736
Original creator: theodleif
